Pressure Gauge
Product Features
Pointer type pressure gauge: calibrated with dual scale reading for pressure and force in psi and MPa.
Silicone oil filled with good anti-seismic performance
Stainless steel outer case, anti-impact surface design, with good safety and durability
YJT series gauge adaptor can facilitate the connections between YLB series pressure gauge and various hydraulic tools
External thread of gauge adaptor is connected with cylinder and pump station, female thread is connected with hose and pressure gauge
Technical Parameters
|
Model |
Max. Working Pressure |
Range |
Dial diameter |
Interface thread |
|
（MPa） |
（MPa） |
（mm） |
||
|
KET-YLB-70-63 |
0-70 |
0-100 |
63 |
NPT1/4 |
|
KET-YLB-70-100 |
0-70 |
0-100 |
100 |
M20×1.5 |
|
KET-YLB-150 |
0-150 |
0-160 |
100 |
M20×1.5 |
|
KET-YLB-160 |
0-160 |
0-160 |
100 |
G1/2 |
|
KET-YLB-180 |
0-180 |
0-200 |
100 |
G1/2 |
|
KET-TLB-200 |
0-200 |
0-250 |
100 |
G1/2 |
|
KET-YLB-250 |
0-250 |
0-300 |
100 |
G1/2 |
|
KET-YLB-300 |
0-300 |
0-350 |
100 |
G1/2 |
|
KET-YLB-400 |
0-400 |
0-450 |
100 |
G1/2 |
